Cross Flow Blower

Cross Flow Blower

MOQ : 500 Piece

Business Type Manufacturer, Exporter
Dielectric Strength 1500V/1minute/1mA
Insulation Resistance 500 V DC/100 MΩ
Insulation Class B
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Operating Temperature
-10 degree C to 60 degree C
Drop Test
50 Cm in Original Packing
Vibration
10 Minutes/Plane, 15Hz, 2mm - Amplitude
Bump Test
2000 bumps, 40G, 2-3 bumps/sec
Humidity
45 + 5 degree C, 90 + 5% RH, 168 hrs
Technical Details

Cross Flow Blower is also known as a tangible lower, which is an air-moving device. It is commonly used in various applications such as ventilation, heating, air-conditioning and refrigeration system.


It includes rectangular or cylindrical housing containing an electric motor and impeller blades. Any reputed Cross Flow Blower Manufacturer will ensure a quality product is delivered. A cross-flow blower draws air into the house through an inlet and forces it out in perpendicular directions which results in a cross-flow of air.


It is achieved through the rotation of the impeller that has helical or curved blades. They are favoured for their ability to evenly distributed flow across a wide area. All you need to do is check with a Cross Flow Blower Exporters for the right product.


They facilitate air circulation, ventilation and cooling. These laws are also used in electronics, cooling for dissipating heat from electronic components. There also found in appliances such as air, curtains, hairdryers, and wherever airflow is essential various factors that need to be considered when selecting a cross-flow blower is that it includes motor power, impeller design and the dimension of the housing.


You can find the best deal from a renowned Cross Flow Blower Suppliers. These factors affect the efficiency and performance of the blower. They are also used in electronic cooling applications for dissipating heat generated by electronic components that operates by generating the airflow through a combination of centrifugal force and the shape of the impeller blades.


These products are manufactured and exported by numerous Cross Flow Blower Exporters from India, ensuring customers have access to high-quality products that meet international standards.


With so many applications, it is always a smart decision to buy the best quality product that will serve the purpose without any issues in the long run. All you need to do is conduct some research about the product and what you are looking for.

Yes! I am interested


Drawings & Dimensions

Drawings & Dimensions

Electrical Specifications

Model No. Operating Voltage Power (On Load) TYP RPM (On Load) LVS Max. Max. Pressure MM. Water Free Airflow Litres/Sec
MCBH621L/2L-F6A 230V 34W 1800 min. 140 V 3.5 74
MCBH621L/2L-G3B 230V 24W 1300 min. 140 V 2.8 54
MCBH630L/2L-F6A 230V 38W 1500 min. 140 V 3.1 83
MCBH630L/2L-H4B 230V 28W 1300 min. 140 V 3 75
MCB1031L/2L-E3 230V 33W 1250 min. 120 V -- 120
