500 Piece (MOQ)
Business Type | Manufacturer, Exporter |
Dielectric Strength | 1500V/1minute/1mA |
Insulation Resistance | 500 V DC/100 MΩ |
Insulation Class | B |
Click to view more |
Preferred Buyer From
Location | Worldwide |
Product Details
Cross Flow Blower is also known as a tangible lower, which is an air-moving device. It is commonly used in various applications such as ventilation, heating, air-conditioning and refrigeration system.
It includes rectangular or cylindrical housing containing an electric motor and impeller blades. Any reputed Cross Flow Blower Manufacturer will ensure a quality product is delivered. A cross-flow blower draws air into the house through an inlet and forces it out in perpendicular directions which results in a cross-flow of air.
It is achieved through the rotation of the impeller that has helical or curved blades. They are favoured for their ability to evenly distributed flow across a wide area. All you need to do is check with a Cross Flow Blower Exporters for the right product.
They facilitate air circulation, ventilation and cooling. These laws are also used in electronics, cooling for dissipating heat from electronic components. There also found in appliances such as air, curtains, hairdryers, and wherever airflow is essential various factors that need to be considered when selecting a cross-flow blower is that it includes motor power, impeller design and the dimension of the housing.
You can find the best deal from a renowned Cross Flow Blower Suppliers. These factors affect the efficiency and performance of the blower. They are also used in electronic cooling applications for dissipating heat generated by electronic components that operates by generating the airflow through a combination of centrifugal force and the shape of the impeller blades.
These products are manufactured and exported by numerous Cross Flow Blower Exporters from India, ensuring customers have access to high-quality products that meet international standards.
With so many applications, it is always a smart decision to buy the best quality product that will serve the purpose without any issues in the long run. All you need to do is conduct some research about the product and what you are looking for.
Drawings & Dimensions
Electrical Specifications
Model No. | Operating Voltage | Power (On Load) TYP | RPM (On Load) | LVS Max. | Max. Pressure MM. Water | Free Airflow Litres/Sec |
MCBH621L/2L-F6A | 230V | 34W | 1800 min. | 140 V | 3.5 | 74 |
MCBH621L/2L-G3B | 230V | 24W | 1300 min. | 140 V | 2.8 | 54 |
MCBH630L/2L-F6A | 230V | 38W | 1500 min. | 140 V | 3.1 | 83 |
MCBH630L/2L-H4B | 230V | 28W | 1300 min. | 140 V | 3 | 75 |
MCB1031L/2L-E3 | 230V | 33W | 1250 min. | 120 V | -- | 120 |
